There are a few different design types around that affect the complexity of the clock build. Word Clocks tell the time using a matrix of words or numbers and letters and have been around for many years.
WRITTEN WORD CLOCK FULL
This clock is based on the original Word Clock by Wouter Devinck full details on his Instructable & GitHub and the "Catalan" Pijuana Word Clock software based on Wouter Devinck's clock (this is a fork off the original Wouter Devinck design) here GitHub. Leave R5 connected to PIN D7 via 0v.Įdit 13/12/17 Corrected fault on touch sensors on Tetris game now v3.8
There are touch pads in each corner to setup and control the clock.Įdit Do not use automatic summer winter correction as there is a bug that causes the RTC to loose the time on power loss. The Clock measures 500mm x 500mm (19.68" x19.68") weighs 12lb (5.5Kg) and is designed to be wall mounted. There is an option for PIR or Doppler Radar control so the clock automatically turns off when no one is in the room. Without a Master clock time is controlled by the Word Clock's built in temperature compensated real time clock. The clock can be stand alone or run as a slave off a Master Clock if required. There are also modes for digital clock, analogue clock, temperature & humidity, & also three games, Game of Life, Simon & Tetris. Code v4.5 works for both PIR and Doppler Radar modules. V4.5 the clock now checks for movement on the quarter hour and will turn off the display if no movement detected.
NEW v4.6 onward a hidden switch enables/disables the touch sensors to prevent unauthorized clock setting. NEW Jason Groves has designd his own version of this clock on PCB.
Further details on this build on my site here Word ClockĪrduino Word Clock with minute resolution of time in words and linear display of seconds.
